Commercial Embroidery Machine with 15 Needles 13' x 20' LCD Embroiderer Pattern for Cap Hat T-Shirt Laser Positioning 1501
Commercial Embroidery Machine with 15 Needles 13' x 20' LCD Embroiderer Pattern for Cap Hat T-Shirt Laser Positioning 1501
Regular price
$9,651.50
Sale price
$9,651.50
Regular price
$14,450.59
Specifications
| Place of Origin | China |
| Main Color | White |
| Main Material | Iron |
Dimensions & Weights
| Assembled Length (in.) | 29.50 |
| Assembled Width (in.) | 27.20 |
| Assembled Height (in.) | 67.30 |
| Weight (lbs) | 330.75 |
Product Features
- 1. 15-needle Single-head Embroidery Machine: 1-12 needles are suitable for soft fabrics, 13-15 needles are suitable for hard fabrics, more professional than small embroidery machines, More work efficient than similar commercial embroidery machines.
- 2. Embroidery Area: 13' x 19.7'(330 x500mm) , Max 1000 needles/min, delicate without broken lines at high speed, 270-Degree Cap Rotation, Use 110V -220V 50/60Hz power supply.
- 3. High-definition Color 10' LCD Touch Screen Control: Powerful, and can freely switch the patterns you want according to your needs, the screen allows you to preview your design in advance. Supports more than 14 multi-languages, supports automatic thread trimming and color changing.
- 4. Supports Multiple Input Modes: The Maximum memory can save up to 800 patterns. Support USB interface WiFi and Bluetooth.
- 5. Widely Applicable: Widely used in household, industry, and commercial channels. Suitable for all kinds of clothing, T-shirt, hats and other knitting products. The design of the bottom casters is free and flexible. Easy to assemble and disassemble. You can choose according to the type of embroidery to change the machine structure.
Description
Single Head Computerized Embroidery Machine 15 Needles
PRODUCTS FEATURES
1. Free choice of 1-15 needles, double rows of needles, high efficiency at the same time.
2. Electirc control systm : DAHAO A15, 10-inch high-definition color LED touch screen, full screen supports design track preview.
3. The host computer is designed with multiple functions, and the system supports 14 languages including Chinese, English, Turkish, and Spanish.
4. Freely switch between WiFi wireless network and 3 USB ports.
5. Support automatic start and 200 color changes.
6. DC 36V power switch, stable and reliable.
7. Recognize various format like DST,DSB & MORE .
8. After replacing the cap frame, the cap frame will automatically rotate 180 degrees.
9. Adjustable speed -Max speed 1000RPM.
10. Pre-time design trace capable.
11. Pinhole precision machine workmanship is exquisite, high-quality materials will never rust.
12. Automatic winding device.
13. Rotary hook:Japanese rotary hook
14. Efficient and fast switching between finished garment frame and hat frame.
15. 110V-220V adapted to all eletriccity enviroment.
16. Restarting the machine after a power failure will automatically restore the embroidery function, so there is no need to worry about needle and thread misalignment.
17. Laser positioning function.Freely slide according to the focus of the laser red dot needle position.
18. The bracket has movable casters, which can be rotated 360 degrees and can be easily pushed by a single person.
19. Easily assemble and disassemble the bracket panel to meet your needs for embroidery of different products.
Technical Specifications
1. 10 inch touch screen computer
2. Maximum number of patterns saved in memory: 800
3. Memory capacity: 100 million stitches
4. Screen resolution ratio: 1280*8003
5. Network port speed:100Mbps
6. Supported method for data 7.Exchange: USB disk, netwofk5.
8. Control precision: Minimum controllable stitch intervalis 0.6.
9. Stitch range:0.1mm~12.7mm
10. System supports Chinese, English, Turkish, Spanish, and so on Total 14 kinds languages
Touch screen
It adopts high-brightness liquid crystal display and touch screen.
Three buttons make perations more efficient.
Needle Wire Rack
1. RLASTIC TUBE Keep the thread walk well to Avoid windy and shaking.
2. Connect each interface in an orderly manner without knotting
3. High quality material
4. Never rust material
5. Auto thread trimmer and auto color change.
6. The number of needles canbe increased as required.
Home-use & Commercial 15Needles Single head Embroidery Machine
1. This embroidery machine is suitable for most styles, and you can use it according to your needs. It not only combines the lightness of other models with 360-degree movable casters, one person can easily change its placement, and adds height Efficiency The advantage of double-head machines operating at the same time greatly improves production efficiency and saves you precious time.
2. We recommend 1-12 needles for softer fabrics, and 13-15 needles for harder fabrics. 12 /15 needles option Max speed 1200 RPM Automatic color change,auto cutter,thread break detection.You can choose freely according to your needs. Trust me once you use it After using it, you will fall in love with this embroidery machine.
Button
Press the button to start embroidery, pause embroidery, green means normal operation, red means off.
Technical Details
| Model: | CH-1501 |
| Features: | Finished garment, cap,flat embroidery, rmore applications |
| Number of head(needle): | One Head 15Needles |
| Embroidery Area: | 13' x 19.7'(330 x500mm) |
| Computer: | DAHAO A15, 10 inch Touch Screen(10' Lcd Display) |
| Max Speed: | 1000 stitches per minute |
| Main Motor: | Servo motor |
| Rotary Hook: | Japanese rotary hook |
| Power Supply: | 110V-220V, 50/60Hz, 200W |
| Operate Manual language: | Chinese. English, Arabic, Spanish, Turkish, Russian French, Portuguese. Thai, Dutch, German, ltalian, Polish etc |
| Main Accessories: | Finished garment frame, cap frame, Aluminum frame, bobbin winder device, easy broken parts, tool etc |
| Optional Device: | Cording device, Sequin device, Beads device, Thermal cutting device, Eyelet device, Robot frame device(shoes device), Socks device,et |
| Cap System | 270-Degress wide angle |
| Net weight: | 330.75lbs (150kg) |
| Package weight: | 396.90lbs (180kg) |
